MTL1144 voltage/current input isolator 1 channel for 1V/5V/10V and 20mA inputs The MTL1144 is a single channel signal converter which can accept 0-1V, 0-5V, 1-5V, 0-10V, 0-20mA and 4-20mA inputs and converts the signal to 4-20mA for...
STRAIN-GAUGE BRIDGES- MTL7761ac Single strain-gauge bridges This shows an arrangement using two or three barriers, which is safe in IIC gases. With the MTL7761ac, the circuit is powered from a 12V (±6V), 214Ω (107Ω + 107Ω) source. I...
MTL7700 range barriers protect devices located in all normally occurring explosive atmospheres, including air/flammable gas mixtures, dusts and fibres. Applications covered include the protection of installations incorporating uncer...
The MTL7758+,MTL,MTL7755AC,MTL7758-,MTL7761ac,MTL7761Pac range, with their advanced features, should be regarded as your first choice for all new designs or installations. The recommendations below are based therefore on the MTL7700 r...
The MTL4517/MTL5517 enables two safe-area loads to be controlled, through a relay, by proximity detectors or switches located in a hazardous area. Line faults are signalled through a separate relay and indicated on the top of the mo...
